Elevah65 Move Picking
Elevah® 65 MP is a stock picker which can reach a working height of 6.5 m and is able to move around easily even in very small spaces.
Specifications
Maximum Work Height
6.50 M
Measurements
78 X 128 CM H:172 CM
Maximum Capacity
200KG (OPERATOR + LOAD)
Weight of Machine
830 KG
Platform Load Capacity
Load up to 100 kg
Adjustment Type
Electric
Standard Colouring
Grey and orange. Custom colours on request.
Areas of Use
Picking and/or storage of small parts or bulk goods, organisation of warehouses and shelves in factories, shopping centres, wholesale shops, etc.
Closable
To save space
Double side access
The access is easy and safe thanks to the double side entrance.
Comfortable and ergonomic
The position of the platform prevents excessive strain on the operator
Designed for picking, storage, organization of warehouses, shelves and logistics, Elevah 65 Move Picking is the picking platform that allows to work up to 6.5 m.
The handy picking plate, foldable and electrically adjustable, allows to lift up to 100 kg.
Compact - only 78x178 cm - and with a turning radius equal to zero that allow the operator to work quickly and comfortably. This platform is easy to drive even in the most narrow areas with little room for maneuver.
The access is easy and safe thanks to the double side entrance.
Work is safer but also faster and easier: thanks to the possibility to electrically adjust the plate, loading and unloading operations can be carried out ergonomically, reducing efforts as much as possible.
Easy and handy to move, it can be driven with one hand thanks to the joystick.
In the equipment and accessories section, you can find the list of standard components and accessories to customize your Elevah 65 Move Picking.
- FRONT, REAR AND CEILING ANTI-COLLISION RADAR
- BASKET BLOCK: max. 1,95 m
- BLUESPOT1 AND BLUESPOT2 (driving direction signalling light)
- ANTI-CRUSHING PROTECTION UNDER THE BASKET
More Optional:
- DIFFERENT COLORING OF MACHINE UPON REQUEST
- DIRECTIONAL LOCKING OF SWIVEL WHEELS
- TRUCK LOADING AND UNLOADING SYSTEM
The machine can work at temperatures between -10° C and +40 °C
General
- Max. working height: 6.50 m
- Max. capacity: 200 kg
- Number of people: 1
- Use: Internal – External
Dimensions
- A — Closed machine height: 1720 mm
- B — Minimum platform height: 460 mm
- C — Maximum platform height: 4700 mm
- D — Base overall dimensions: 1280 mm
- E: 1780 mm
- F: 780 mm
- G — Cage dimensions: 640 mm
- H: 710 mm
- Machine weight: 830 kg
Fixed Picking Tray
- K — Tray dimension: 440 mm
- L: 740 mm
- Tray capacity: 20 kg
Wheels
- Drive wheels dimension: Ø 220 × 65 mm
- Swivel wheels dimensions: Ø 200 × 50 mm
Picking Platform
- Adjustment: Electrical
- Stroke: 600 mm
- Minimum height from the ground: 820 mm
- Maximum height from the ground: 5650 mm
- I — Dimensions: 500 mm
- J: 680 mm
- Capacity: 100 kg
Performance
- Power supply: 24 V
- Batteries: Lead-Acid 12V 105 Ah
- Battery charger: 110V – 220V
- M — Maximum climbing ability: 15%
- Climbing ability at height: 2.5%
- Internal turning radius: 0
- External turning radius: 1095 mm
- Max. speed (rising – descending): 0.2 m/s
- Maximum speed (with basket on the ground): 5 km/h
- N — Maximum pressure for wheel at full load*: 3.6 kN
- Work cycles (with fresh batteries)**: Approx. 130
Notes
* Maximum pressure measured when the weight of the platform plus maximum basket load is fully distributed on one side (totally asymmetric load).
** A work cycle = 20 m self-propelled movement + full ascent + full descent + adjustment of the loading platform.
Complies with European regulations for man-up forklift trucks: UNI EN ISO 3691-1.
Safety Equipment
- Maximum capacity control: Via relief valve
- Electronic inclinometer: With anti-tip function
- Double entrance: 2-leaf access doors with locking control
- Foot pedal: Signals operator presence
- Potentiometer: Adjusts maximum translation at the basket edge
- Acoustic alarm signal
- Motion buzzer
- Light movement indicator
- Picking platform capacity control: Electronic motor control (only on electrical platform)
- Automatic electronic parking brake
- Horn
- 2-sash access doors to basket: With closure control
- Joystick safety: Safety catch to prevent accidental activation
- Drive wheels protection: IP65
- Emergency descent: Manually activated, basket lowers to base
Ergonomics and Functionality Equipment
- Storage shelf: Mounted on the column
- Picking platform side guards
Electronics, Power Supply and Batteries
- Self-propulsion: Proportional
- Lifting block: Activates at 80% battery level
- Hour meter: Located on basket
- Battery charge indicator: Located on basket
Safety Devices
Picking Platform
Ergonomic and Functional Equipment
Batteries
Colours
